Peerless Light Transmittance (≥ 96.5\% - 98.5\%): Utilizes double-sided nanometer SiO2 anti-reflective (AR) coatings to eliminate surface reflection losses, driving light transmission up to 98.5% to deliver a direct 5% - 10% crop yield increase.
Ultra-Pure Low-Iron Substrate: Manufactured from premium float or patterned low-iron glass with iron oxide content Fe2O3 ≤ 0.015% (150 ppm), eliminating greenish light distortion and maximizing Photosynthetically Active Radiation (PAR).
Permanent Hydrophilic Anti-Condensation: Coated with a durable hydrophilic nano-film that forces moisture to form a transparent water film rather than light-blocking water droplets, offering self-cleaning, anti-dust, and anti-dripping benefits.
Pyrolytic Sol-Gel Coating Durability: Thermally fused into the glass matrix during tempering, ensuring high scratch resistance, weatherability, and chemical stability that will not peel off under high-humidity greenhouse environments.
Hail & Storm Certified Security Rating: Available in 3.2 mm and 4.0 mm physically toughened configurations compliant with EN 12150 standards, featuring an ultra-low spontaneous breakage rate below 0.05%.
| Quantity: | |
|---|---|
Are you engineering an automated high-tech plant factory, constructing a commercial tomato glasshouse in a light-deprived region, or seeking maximum solar energy conversion for high-value floriculture? Shandong Weihua Glass manufactures premium Double-Sided AR Coated Low-Iron Glass (Anti-Reflective Greenhouse Glass) engineered specifically to deliver near-total solar light passage, eliminate reflection energy loss, and maximize crop harvest potential.
Standard float glass reflects away approximately 8% of incoming solar energy due to natural surface reflection. In modern precision agriculture, this lost light directly corresponds to lost harvest revenue. Following the fundamental rule of greenhouse agronomy— "1% additional light equals 1% additional crop yield" —Weihua’s AR coated glass solves this bottleneck. By applying nanometer-scale silica (SiO2) anti-reflective thin films to both sides of ultra-clear glass panes, we drop surface light reflection down to <1.5%, allowing up to 98.5% of solar photons to flood into your growing canopy.
Using advanced sol-gel dipping or precision spraying technology, a porous silica layer with a calibrated refractive index is deposited on both glass surfaces. This destructive interference coating neutralizes solar reflections across the visible light spectrum (380 nm - 780 nm), unlocking maximum PAR spectrum transmittance for your plants.
Condensation droplets on standard greenhouse glass create severe light reflection barriers and drip onto delicate leaves, spreading fungal diseases. Weihua's permanent AR coating is naturally hydrophilic. Moisture flattens into a micro-thin, continuous transparent water layer that flows smoothly down to roof gutters without blocking light rays or dripping onto crops.
Technical Property | Double-Sided AR Low-Iron Glass | Standard Uncoated Glass | Agronomic & Commercial Value |
Total Light Transmittance | ≥ 96.5% - 98.5% | 88.0 % - 89.0 % | Maximized light throughput; boosts crop yield by 5%–10%. |
Surface Reflection Loss | < 1.5% (Both sides) | ≈ 8.0% | Minimizes photon energy bounce-back. |
Iron Oxide Content (Fe2O3) | ≤ 0.015% (150 ppm) | 0.1% - 0.3% (1000 ppm+) | Pure spectrum transmission with zero greenish distortion. |
Coating Processing Type | Thermally Fused Sol-Gel SiO2 | N/A | Weatherproof bond that resists cleaning and high humidity. |
Standard Thickness Options | 3.2 mm / 4.0 mm | 4.0 mm - 6.0 mm | Lightweight 3.2 mm tempered panes reduce roof load stress. |
Spontaneous Explosion Rate | < 0.05% | 0.1% - 0.3% | Ultra-pure raw material reduces NiS impurities; hail safe. |
Permanent Pyrolytic Fusion Bonding: Cheap AR coatings degrade, flake off, or collect dust over time. Weihua fuses the nano-silica coating directly into the glass matrix during high-temperature tempering, ensuring a durable, scratch-resistant surface that withstands automated greenhouse washing equipment.
100% Factory Sizing & Frame Synchronization: Ordering glass panes that do not fit the roof aluminum gutters causes costly installation delays. Weihua works directly with your structural CAD submittals, delivering CNC-cut, bevel-edged tempered glass panels that drop seamlessly into your roof framing system.
Elite Glass & Hardware System Integration: Sourcing greenhouse glass from one supplier and roof capping profiles or rubber gaskets from another often leads to sizing errors and seal failures. Weihua provides complete system integration—pre-matching glass pane dimensions with custom EPDM gaskets, aluminum capping profiles, and structural fasteners.
Engineered Moisture-Proof Maritime Packaging: Ocean freight transit can cause moisture staining (white haze) on raw or coated glass surfaces. Weihua packs all agricultural glass inside reinforced L-frame timber crates lined with moisture-barrier films, non-reactive interleaving powder, and desiccant packs, ensuring pristine, scratch-free surfaces upon delivery.
