Qingdao Wanda Fenglong Bay Creative Plaza Curtain Wall

1. Project Overview

Qingdao Wanda Fenglong Bay Creative Plaza is a large commercial and office complex located in the West Coast New Area of Qingdao, China.
The project features expansive glass curtain wall façades with strict requirements for energy efficiency, wind-load resistance, transparency, and long-term durability.
Due to the seaside environment and high wind pressure, the client needed high-performance Low-E insulated glass with excellent structural reliability.

Project Type: Commercial Complex
Location: Qingdao, China
Total Construction Area: Approx. 85,000 ㎡
Glass Supplied: 10,900 ㎡

2. Glass Configurations Supplied

We provided three customized insulated glass configurations based on façade requirements, wind loads, and architectural design:

1) 6 Low-E (CSG) + 12A + 6 Double-Tempered IGU — 7,500 ㎡

• Used for standard curtain wall areas

• Balanced performance with excellent clarity and thermal insulation

2) 8 Low-E (CSG) + 12A + 8 Double-Tempered IGU — 2,300 ㎡

• Applied to high-rise and large-span façade sections

• Enhanced structural strength and wind-load resistance

3) 6 Low-E (CSG) + 12A Double-Curved Tempered IGU — 1,400 ㎡

• Designed for curved façades, corners, and special architectural zones

• Ensures seamless visual continuity and stable structural performance

All glass products passed CE, SGCC, and ISO9001 certification, with full quality testing before shipment.

3. Key Technical Highlights

High Wind-Load Resistance

• Double-tempered structure

• High-strength spacer and structural sealant

• Designed to withstand strong coastal wind conditions

Superior Thermal Performance

• Double-silver Low-E coating from CSG

• Reduces solar heat gain by 20–30%

• Improves indoor energy efficiency throughout summer and winter

Precision Curved IGU Production

• CNC-controlled forming

• Curvature tolerance within ±1.0 mm

• Ensures smooth façade transitions and architectural aesthetics

Strict Quality Control

• CNC cutting and double-edge grinding (precision ±0.5 mm)

• Automated tempering line with uniform heating

• Fully automatic butyl sealing for IGU stability

• Long-distance reinforced packaging using metal–wood frames

4. Installation & Delivery

The project was completed in 6 shipment batches, transported using 40HQ containers.
Each shipment included:

• Metal + wooden composite frames

• Corner protectors

• Moisture-proof wrapping

• Multi-layer strapping for stabilization

Total Delivery Time: 32 days
We also provided installation drawings, curved glass mounting guidance, and IGU sealing recommendations to support on-site teams.

5. Final Results

• The completed glass façade achieved impressive transparency and daylight performance

• Low-E IGU significantly reduced heat transmission

• Interior temperature stability improved by 4–6°C

• Curved glass sections delivered a continuous and dynamic architectural appearance

• The client expressed strong satisfaction with quality, delivery, and technical support
