Superior Thermal Insulation: Constructed with two or more glass panes separated by a sealed aluminum or warm-edge spacer. Drastically reduces heat transfer to lower building energy costs.
Excellent Noise Reduction: Effectively dampens external sound waves, creating a quiet and comfortable indoor environment for commercial and residential spaces.
Anti-Condensation & No Fogging: Equipped with premium molecular sieve desiccants and dual-seal technology (Butyl & Silicone) to prevent internal moisture and fogging.
Factory-Direct Supply: Manufactured by Shandong Weihua Glass. We offer flexible glass combinations (Low-E, Tempered, Tinted) with strict quality control and global certifications.
Versatile Applications: Perfect for energy-efficient windows, structural curtain walls, office facades, glass doors, and refrigeration display cases.
| Quantity: | |
|---|---|
Are you seeking an advanced glazing solution to improve thermal comfort and reduce carbon footprints in your next architectural project? Shandong Weihua Glass offers industrial-grade, custom-built insulated glass units (double or triple glazing) engineered for maximum energy efficiency and durability.
By combining premium float glass, optional Low-E coatings, and state-of-the-art automated sealing lines, our insulated glass effectively blocks external heat in summer and retains indoor warmth in winter. Whether you are sourcing for large-scale commercial curtain walls or premium residential window systems, Weihua provides structural integrity and thermal performance you can rely on.
Feature (特性) | Available Options (可选参数/规格) |
Glass Combinations | Clear, Ultra-Clear, Low-E (Single/Double/Triple Silver), Tinted, Reflective, or Laminated Glass |
Glass Thickness | 4 mm, 5 mm, 6 mm, 8 mm, 10 mm, 12 mm, 15 mm etc. |
Spacer Width (Aluminum/Warm Edge) | 6 mm, 9 mm, 12 mm, 15 mm, 16 mm, 19 mm, 20 mm, 24 mm etc. |
Gas Filling | Standard Air or Premium Argon Gas (for enhanced thermal performance) |
Size Range | Min: 300 mm X 300 mm |
Sealing System | Primary Seal: Polyisobutylene (Butyl) | Secondary Seal: Polysulfide or Structural Silicone Sealant |
Certifications | CE (EN1279), ISO9001, CCC, SGCC (Standard for US/EU markets) |
Advanced Low-E Technology: Our single, double, or triple silver Low-E coatings reflect infrared heat while allowing natural light to pass through, significantly optimizing the building's U-value and SHGC.
Dual-Seal Longevity: We utilize a automated dual-sealing process that ensures a gas-tight environment, preventing argon leakage and guaranteeing a lifespan free of internal condensation.
Optical Clarity & Precision: Processed with high-end cutting and washing systems, our IGUs offer flawless visibility without distortion or internal dust contamination.
Specify Configuration: Define your glass and spacer makeup (e.g., $6\text{mm}$ Low-E + 12A + $6\text{mm}$ Clear). Specify if Argon gas is required.
Enter Dimensions: Provide the precise width, length, and total unit thickness required for your window frames or curtain wall systems.
Choose Secondary Sealant: Select structural silicone for structural curtain walls (UV exposed) or polysulfide sealant for standard framed windows.
Submit Project Details: For complex structural glazing, curved units, or stepped IGUs, upload your CAD files for an accurate technical review and quote.
